Products Description
YKK series MV/HV high voltage ac motor is a new generation product based on the SIMO company's long-term stable high-voltage three-phase asynchronous motor's experience of design and manufacturing, combined with the latest international standards.
It can be used in driving different kinds of machinery, such as ventilators, compressors, water pumps, crushers, cutting machine tools, transportation machinery and other equipment, and can be used prime power by coal mines, machinery industries, various industrial and mining companies.
Main Technical Parameters
|
Frame: |
H355~H1000 |
|
Power Scope: |
160~8000kW |
|
Voltage: |
3000V, 3300V, 4160V, 6000V, 6600V, 10000V, 11000V |
|
Frequency: |
50Hz, 60Hz |
|
Number of Poles: |
2P, 4P, 6P, 8P, 10P, 12P, 16P |
|
Speed |
3000rpm, 1500rpm, 1000rpm, 750rpm, 600rpm, 500rpm, 370rpm |
|
Cooling Mechod |
IC611 |
|
Protection Grade |
IP54, IP55 |
|
Insulation Class |
F(155℃), H(180℃) |
|
Duty: |
S1, S4, S5, S6, S9 |
|
Mounting Type |
B3/V1 |
Why choose Simo Brand YKK series of Motor?
Simo YKK series of high voltage ac motor is three phase squirrel cage totally enclosed asynchronous motor. As the best seller in Simo products system, YKK motor has outstanding advantages of efficiency, energy saving, lower noise, low vibration, light weight and easy for maintaining. Through several decades of verification by the customers and market in and out of China, SIMO YKK motor is one of the most reliable electric motor for industrial use.
To meet with different clients' needs, the motors can be made into foot mounting or vertical mounting, insulation class H, double shaft ends, TH3, plateau and other situations.
Great quality is the secret that Simo motor can be outstanding all through the 67 years in electric motor manufacturing industry. We have really strict control systems on the material suppliers choosing and reviewing, material inspection, process checking, motor testing, packing and transporting.
Product Features
This series of high and low voltage three-phase asynchronous motor has many advantages, such as compact structure, light weight, high efficiency, energy saving, low noise, low vibration, high reliability, long service life, easy installation and maintenance,
etc.
Operation Conditions
Ambient temperature is -15℃~+40℃; Altitude ≤1KM; and monthly average air humidity ≤90% (If temperature is 25℃).
Wide Application
This series of high voltage ac motor is applied in all kinds of different machinery, such as air ventilators, compressors, water pumps, crushers, cutting machines and other equipment, and it can be also regarded as prime motor among coal mine, machinery industry, power plant and other kinds of industries and mining enterprises.
