Big Permanent Magnetic Synchronous Motor

Big Permanent Magnetic Synchronous Motor

Big permanent magnet synchronous motor has the advantages of simple structure, small size, high efficiency and high power factor. With the special inverter, it can be used with adjustable speed and a wide range of speed regulation. More information welcome to contact with us sales@simo-motor.com.cn
Send Inquiry

Main Data

Type: PMSM Permanent Magnetic Synchronous Motor

Model1: TCYP5-280S-6

Model2: TCYP5-280M-6

Power: 45kw 55kW

Frame size: 280mm

Voltage: 380V 490V 460V 660V

Rated Frequency: 33.3Hz

Cooling Method: IC416

Protection Grade: IP55

Insulation: H 180℃

Speed:1000rpm

Poles: 6P

Efficiency: 95.8% 96%

Power Factor: Cos: 0.9

Weight: 619kg 737kg

VFD: XBP480T45GB-plus XBP480T55GB-plus


Introduction



Big permanent magnet synchronous motor has the advantages of simple structure, small size, high efficiency and high power factor. With the special inverter, it can be used with adjustable speed and a wide range of speed regulation. Permanent magnet synchronous motors have been used in metallurgical industry (ironmaking plants and sintering plants, etc.), cement industry (ball mills), rubber industry (internal mixers), petroleum industry (pumping units), textile industry (double twisting machines, spinning frames) and other industries of medium and low voltage motors have achieved performance, and gradually accumulated design and operation experience.



Big Permanent Magnet Synchronous Motor, welcome to choose SIMO motor.


Great Materials

China Simo Make PMSM motor adopts best materials for stator, rotor and commutator to ensure the perfect performance and high efficiency.

  • SIMO motor stator

    STATOR
  • SIMO motor rotor

    ROTOR
  • SIMO motor end cover

    END COVER
  • SIMO motor assembling
    ASSEMBLY

YCTP5 315-6 IC416 data 1

YCTP5 IC416 drawing1

YCTP5 IC416 dimensions 1

Ordering note

1,Please check product introduction , to confirm the motor type etc before ordering , please note power, voltage, speed ,exciting type ,exciting voltage, structure and mounting etc in the contract.

2,Please note some special requirements for two shaft extensions ,terminal box, testing-speed in the contract.

3,when the customers have some other needs, please contact us before .
